Granit 1920i Endüstriyel DPM Alan Görüntüleme Barkod Okuyucu

The direct part marks used in industries such as automotive, pharmaceutical, defense and aerospace are hard for many scanners to read. Not so for the tough Granit™: 1920i industrial scanner. Part of the durable Granit family, the Granit 1920i scanner captures virtually any direct part mark with ease, along with standard barcodes on printed labels.

• The Honeywell specialized DPM decoder assures high and accurate reading yields on dif cult direct part marks.
• An innovative multi-illumination system enables scanning of virtually any type of direct part mark –: regardless of size, surface, marking method or contrast.
• A laser-spot aimer, omnidirectional scanning and features such as automatic cycling through multiple illumination modes make it easy for operators to target and use the scanner.
• Tested to withstand the toughest environments: rated IP65 and can withstand 5,000 tumbles from 1 m (3.3 ft) and 50 drops to concrete from 2 m (6.5 ft) –: and temperatures as low as -30°:C (-22°:F).
• With its ability to read standard 1D and 2D barcodes on printed labels, the scanner provides companies with maximum value: a single solution to meet their end-to-end scanning needs.

Garanti 2 yıl
Marka Honeywell
Boyutlar (LxWxH) 134 mm x 74,5 mm x 193 mm
(5,27 x x 2,93 x x 7,6 inç)
Ağırlık 312 g (11 oz)
Elektrik Giriş Voltajı: 4.0V DC – 5.5V DC
Çalışma Gücü: 2,35 W (470 mA @ 5V DC)
Bekleme Gücü: 0,5 W (100 mA @ 5V DC)
Ana Sistem Arabirimleri: USB, RS-232, Klavye Takozu
Çalışma Sıcaklığı -30 ° C ila 50 ° C (-22 ° F ila 122 ° F)
Depolama Sıcaklığı -40 ° C ila 70 ° C (-40 ° F ila 158 ° F)
Nem % 95’e kadar bağıl nem, yoğuşmasız
Damla 50 2 m (6.5 ft) dayanacak şekilde tasarlanmış -30 ° C (-22 ° F) betona damla
Çevresel Sızdırmazlık IP65
Işık Seviyeleri 0 – 100,000 lux
Tarama Açısı Yatay: 41.4 °; Dikey: 32.2 °
Çamaşır çakılır 5000 1 m (3.3 ft)
ESD ± 20 kV hava deşarjı; ± 8 kV kontak deşarjı
Sembol Kontrastı % 25 minimum yansıma farkı
Pitch, Eğri 1D: ± 45 °, ± 65 °; 2D: ± 45 °, ± 45 °
Tarama Örneği Alan Görüntüleyici
İletişim USB
Min. Çözünürlük 1D 2.5 mil; 2D 4 mil
Okuma Göstergeleri LED, Beeper ve Vibratör
Kod Çözme Özelliği Standart 1D, yığılmış, 2D ve posta sembollerini okur
